Product Information
Description
Hafele 237.67.300 Central Locking System Body
Timberline- modular removable core locking systemModel : CB-120 Application : The choice for fully engineered cabinets Key travel : 180°; 12 mm lift Features : With small lifting pin Installation : Allows for simplified mounting and quick adjustment making installation easy Mounting : Right side of the cabinet only Adjustment : Adjustment to bar moves fixed pin positions Material : Lock case: Nylon
Cylinder housing: Die-cast zincFinish : Zinc Diameter of Cylinder : 16 mm
Optional items:
Snap-In Lock Core, Keyed Different
Snap-In Lock Core, Keyed Alike
Lockbar
Arresting Pin, for Installation in Lockbar
Trim Cap, Press-Fit for Confirmat Head, 12 mm
Bar Retaining Bracket, with Guide LugSpecifications
For detailed PDF specifications, click:
Hafele Catalog Page: selection_10.12-10.14.pdfHafele 237.67.300, 237-67-300, 23767300, 237.67 Specifications/Hafele Catalog - Page# FC10.14:
Click to: Show catalog here ...
Click to: Show catalog in a new page.
