Hafele 421.23.750 Concealed Undermount Slide, Frameless, Full Extension, Soft Close,75 lbs./Pair Salice Futura, 500 mm length
Product Information
Description
Hafele 421.23.750 Concealed Undermount Slide, Frameless, Full Extension, Soft Close,75 lbs./Pair
Salice Futura, 500 mm length
Note: This product can only be purchased in minimum quantity of 6Finish : Zinc Type of closing : Soft & silent, Integrated concealed soft close with 52 mm closing range Type of pull out : Full extension Adjustment : 3 mm height adjustment in front clips Load bearing capacity : 34 kg (75 lbs) per pair
Optional items:
for Internal Drawer Pull-Out
for Salice Futura Slides
for Salice Futura Slides
for Face Frame Cabinets
Flat Countersunk Head, #2 Phillips, with Nibs
Flat Countersunk Head, #2 Phillips Drive
Flat Countersunk Head, #2 Square Drive, with Nibs
Flat Countersunk Head, #2 Square Drive
Flat Countersunk Head with Uni-Drive, Zinc-PlatedCatalog Pages
