Hafele 233.42.700 Glass Door Cam Lock, Symo 3000 For combination with Symo cylinder removable core, Left hand, matt nickel

Product Information

• Description

  Manufacturer: Hafele
  Item: 233.42.700

  Product Title: Glass Door Cam Lock, Symo 3000, For combination with Symo cylinder removable core, Left hand, matt nickel

  Category: Glass Door Cam Lock, Symo 3000, For combination with Symo cylinder removable core

  Item Details …

  - Closure travel : 180°

  - Color/finish : Nickel plated, Nickel plated polished

  - For door thickness min. : 5/32"

  - Area of application : For cylinder cores which are inserted from the front on-site

  - Suitable for : With straight cam

  - Cylinder shape : prepared for round cylinder

  - Version : With straight cam

  - Material : Zinc alloy

  - For glass thickness : 4 – 10 mm

  - Installation : Screw-mount with hexagon nut

  - with key : No

  - Order reference

  - Please order counterpiece for 2-leaf sliding doors.

  - Supplied with:

  - Locking cam

  - Mounting nut

  - Angled striking plate

  - Clamping plate

  - Clamping rosette

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  TCH_Furniture_Cabinetry_Hardware_2022|Page 10.32



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_10.32-10.32.pdf

  Hafele 233.42.700, 233-42-700, 23342700, 233.42


  Specifications/Hafele Catalog - Page# FC10.33: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Lockers & Locking Systems Catalog Return to: All Hafele Catalogs

  Download Adobe PDF Reader





• Required Products & Optional Accessories

  Optional Accessories:



  • Counterpiece, for Glass Door Cam Lock
  • Plate-Cylinder Removable Core, Keyed Alike, Symo 3000
  • Master Key, for Plate-Cylinders/Cut Key
  • Key Blank, Steel
  • Removal Blank, For Symo Universal cylinder core, warehouse locking system
  • STW Pin-Tumbler Cylinder Removable Core, Keyed Different
  • STW Pin-Tumbler Cylinder Removable Core, Keyed Alike
