Hafele 403.31.000 Sliding Door Hardware, EKU Combino L 40, Set For angled wood sliding doors, for door weights up to 88 lbs, 1 Door

Product Information

• Description

  Manufacturer: Hafele
  Item: 403.31.000

  Product Title: Sliding Door Hardware, Hawa Combino L 40, set, For angled wood sliding doors, for door weights up to 88 lbs, Vorfront, for 1 doors, Without soft closing mechanism, With clip-in door stopper

  Category: Sliding Door Hardware, Hawa Combino L 40, set, For angled wood sliding doors, for door weights up to 88 lbs, Vorfront, for 1 doors, Without soft closing mechanism, With clip-in door stopper

  Item Details …

  - Set Components Include:

  - Running gear, for outer door, for screw mounting

  - Guide roller, for outer door, for screw mounting

  - Bottom door stopper, with spring

  - Top door stop

  - Great for home entertainment applications

  - Can be used to hide large flat screen TVs

  - Optional Soft Close mechanism available

  - Top and bottom door stopper, bottom stopper with spring

  - Guided by running gear, ball bearing mounted, plastic-coated rollers

  - Number of doors : 1.00

  - Soft closing mechanism : with clip-in door stopper

  - For door width : ?1,500 mm

  - For door weight : ?40 kg

  - Running position : Bottom

  - Number of rollers : 1.00

  - Height adjustment : -2?–?4 mm

  - Running gear guided by : Ball bearing

  - For door material : wood

  - Door width max. : max. 59 1/16”

  - Door weight max. : 88 lbs.

  - Height adjustable :

  - Cabinet version : with angled wooden sliding doors

  - Set : Set without tracks

  - Area of application : For 1 door

  - For door height : ?1,500 mm

  - For material thickness : 19 mm

  - Door stopper : Top clip-in door stopper or soft and self closing mechanism, for sliding into running track

  - Material/finish : Rollers: Plastic

  - Adjustment facility : Height adjustment: -2?–?4 mm, Depth adjustment facility: ±3 mm, Height +4/-2 mm on running gear using eccentric screwdepth ±3 mm on running gear using eccentric screw

  - Door adjustment via : eccentric screw

  - Installation : Running gear and guide for screw fixing

  - Type of opening : linear

  - Number of doors per system max. : 1 to 3

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  Combino L 40 Mounting Instructions

  TCH_Furniture_Cabinetry_Hardware_2022|Page 7.47



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_7.46-7.47.pdf

  Hafele 403.31.000, 403-31-000, 40331000, 403.31


  Specifications/Hafele Catalog - Page# FC7.63: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Sliding & Roller Shutters Catalog Return to: All Hafele Catalogs

  Download Adobe PDF Reader





• Required Products & Optional Accessories

  Note: Add the current product in cart before ordering required products below ...

  Required Products:

  Double Bottom Running Track, for HAWA Combino L 40 (choose one):


  • for Hawa Combino VF, Length: 8' 2 7/16" for Hawa Combino VF, Length: 11' 5 13/16"

    403.32.926 403.32.936

    Click to order Click to order



  Double guide track, Top, for screw fixing with chipboard screws (choose one):


  • for Hawa Combino VF, Length: 8' 2 7/16" for Hawa Combino VF, Length: 11' 5 13/16"

    403.33.926 403.33.936

    Click to order Click to order
