Hafele 408.31.010 HAWA Folding Concepta 25, 1851 - 2600 mm, left hand

Product Information

• Description

  Manufacturer: Hafele
  Item: 408.31.010

  Product Title: Wooden Folding Sliding Doors, HAWA Folding Concepta 25, set, hinges with soft closing mechanism, Door height 1851–2600 mm, left hand mounting, colorless anodized

  Category: Wooden Folding Sliding Doors, HAWA Folding Concepta 25, set, hinges with soft closing mechanism,

  Item Details …

  - Suitable for 3 doors in combination with Hawa Concepta

  - Number of doors : 2.00

  - For door width : 300?–?700 mm

  - For door weight : ?25 kg

  - Version : Hinges with soft closing mechanism

  - For door thickness min. : 3/4"

  - For door thickness max. : 1"

  - Length (inch) : 2' 1 19/32"

  - For door thickness : 19?–?26 mm

  - Material/finish : AluminiumSteelPlastic, Colorless, anodized

  - Running gear guided by : Ball bearing

  - Installation : Left hand

  - Order reference

  - Strengthening profile cut to required length available on request. Please order connecting plate separately.

  - Supplied with:

  - 1 set

  - 2 Connector connecting profiles for parking pocket (1 top, 1 bottom)


  Additional Information …

  We recommend using the strengthening profile for double systems up to max. 2800 mm without centre panel.2 floor profiles are required for Vorfront construction with 4 doors.

• Data Sheet

  Detailed Data Sheet

• Product Resources

  Installation instructions

  TCH_Furniture_Cabinetry_Hardware_2022|Page 7.132



• Required Products & Optional Accessories

  Optional Accessories:



  • Bottom Profile with Cover Caps, Contact Slope and Drilling Jig, for Concepta 25
  • Magnetic Centering Part with Drilling Jig, for Concepta 25
  • Strengthening profile for cabinet top panel, for Concepta 25
  • Connecting plate, For running track
