Hafele 409.43.712 Lateral Door Opening System, with hinges, support bar, and damper, 40 kg, max door height 2400mm, aluminum, white

Product Information

• Description

  Manufacturer: Hafele
  Item: 409.43.712

  Product Title: Lateral Door System, LIN-X800, White; 2400 mm height

  Category: Lateral Door System, LIN-X800,

  Item Details …

  - Door swings out laterally in a small radius compared to ordinary swing doors, ideal for tight spaces

  - Non handed

  - Adjustable in 4 directions: horizontal, vertical, depth, and parallel

  - Built-in dampers provide smooth soft closing movement

  - Door weight max. : 88 lbs

  - Side panel thickness min. : 15/16"

  - Side panel thickness max. : 1 9/16"

  - Material : Aluminum and steel

  - For door height : 2,400 mm


  Additional Information …

  Designed for overlay applications, but can be installed flush with cabinet or wall. For details contact customer service.

• Data Sheet

  Detailed Data Sheet

• Product Resources

  LIN-X800 Mounting Instructions
