Hafele 499.72.114 Slido Pocket Frame Kit, with Slido D-Line11 50P fitting set, with soft close one direction

Product Information

• Description

  Manufacturer: Hafele
  Item: 499.72.114

  Product Title: Sliding Door Retail Kit, Slido D-Line 11, with 2 m upper track, 50 kg (110 lbs) door weight; with one soft close, 1 track stopper

  Category: Sliding Door Retail Kit, Slido D-Line 11, with 2 m upper track

  Item Details …

  - Number of doors per system max. : 1

  - Number of doors : 1.00

  - For door material : wood

  - Running track length : 2,000.00 mm

  - Length running track (inches) : 78 3/4"

  - Controller installation options : Ceiling installation, Wall mounting

  - Area of application : For single and bypassing sliding wood doors

  - For door height : ?2,032 mm

  - Running position : Top

  - Order reference

  - Order 2 kits for a bypassing application

  - Supplied with:

  - 1 header assembly

  - 2 front vertical studs

  - 2 back vertical studs

  - 2 shoe plates for vertical studs

  - 1 concealed end bracket

  - 1 open end bracket

  - 2 filler strips

  - 1 upper track with key hole

  - 1 Slido D-Line11 fitting set

  - Mounting screws

  - Mounting instructions
