Hafele 663.24.921 Coal Box Caster, Plate Mount, Load-Bearing Capacity 88 lbs. Black

Product Information

• Description

  Manufacturer: Hafele
  Item: 663.24.921

  Product Title: Coal Box Caster, With soft running surface, fixed or free running, Screw-on plate or M10 threaded bolt, Black

  Category: Coal Box Caster, With soft running surface, fixed or free running, Screw-on plate or M10 threaded bolt

  Item Details …

  - Does not leave marks

  - low rolling resistance

  - no flattening under load, therefore longer service life

  - Thread type : Soft

  - Material : Housing: SteelWheel: Plastic (polyamide)Running surface: Solid rubber

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Furniture_Cabinetry_Hardware_2022|Page 6.11



• Specifications

  For detailed PDF specifications, click:
  Hafele Catalog Page: selection_6.11-6.12.pdf

  Hafele 663.24.921, 663-24-921, 66324921, 663.24


  Specifications/Hafele Catalog - Page# FC6.13: Click to: Show catalog here ... Click to: Show catalog in a new page. Return to: Hafele Table, Legs, Casters Catalog Return to: All Hafele Catalogs

  Download Adobe PDF Reader





• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Optional Accessories:



  • Glide, for Press-Fitting into Square Tubes
  • Mounting Plate, with internal thread for threaded bolt
  • Spax® Screw, Pan Head Screw with Uni-drive, Zinc-Plated
