Hafele 911.62.335 Flush Bolt, Slide Action With bolt work on one side, Matt Finish

Product Information

• Description

  Manufacturer: Hafele
  Item: 911.62.335

  Product Title: Flush Bolt, Slide Action, With bolts on one side, Matt Finish

  Category: Flush Bolt, Slide Action, With bolts on one side, Matt Finish

  Item Details …

  - Color/finish : matt

  - Forend width : 19.00 mm

  - Travel : 25.00 mm

  - Length : 151.00 mm

  - Length (inch) : 5 15/16"

  - Material : Stainless steel

  - For door thickness min. : 1 3/8"

  - Area of application : For wood doors

  - Version : with bolt work on one side

  - Deadbolt operation : With slide

  - Locking direction : one-sided

  - Forend design : Flat forend edged

  - Installation : Typically recessed into edge of door

  - Supplied with:

  - Strike Plate

  - Mounting Screws

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  TCH_Architectural_Hardware_2022|Page 3.25



• Specifications
