Hafele 940.42.065 Slido D-Line11 50P Fitting Set, with1 track stopper and 1 soft closing mechanism (1 kit), 94042065, 940-42-065Zoom

Hafele 940.42.065 Slido D-Line11 50P Fitting Set, with1 track stopper and 1 soft closing mechanism

$115.34$144.18You Save: $28.84 (20%)
Item# Hafele-940-42-065
Availability: in stock

Product Information

  • Description

    Manufacturer: Hafele
    Item: 940.42.065

    Product Title: Sliding Door Hardware, Slido D-Line11 50P, set without running track, for 1-leaf wooden sliding doors, ceiling installation and wall mounting, door height adjustable, for door weight up to 50 kg, With soft and self closing mechanism on one side, door width ?499 mm

    Category: Sliding Door Hardware, Slido D-Line11 50P to 120P, set without running track, for 1-leaf and 2-leaf wooden sliding doors, ceiling installation and wall mounting, door height adjustable

    Item Details …

    -     Soft and self closing mechanism:

    - low opening force – easy and convenient operation

    - tested with increased closing speed up to 0.5 m/s

    - Can be retrofitted or replaced at any time

    - Accessibility: Opening force with door weight 50 kg: 20 N / 80 kg: 23 N

    - Shock absorber:

    - Closing speed with shock absorber tested up to 0.4 m/s

    - Number of doors : 1.00

    - For door material : wood

    - Controller installation options : Ceiling installation, Wall mounting

    - Adjustment facility : Height: (3/16") +/-5

    - Area of application : for 1-leaf and 2-leaf sliding doors

    - Note on door weight : per door

    - Running position : Top

    - Adjustment facility : height adjustment

    - Installation : Suspension with screwed on support flange

    - Order reference

    - Please order track, panels and accessories separately. Order 2 sets for 2-leaf sliding doors.

    - Supplied with:

    - 2 running gears (1 with soft and self closing mechanism)

    - 1 clear threshold floor guide

    - 1 track buffer with retaining spring

    - 1 release device with stopper for soft and self closing mechanism


    Additional Information …

    No end cap is available for ceiling installation with fascia on both sides. A pair of end caps can be attached end to end and glued vertically in the centre of the running track (optional).Please note when using shock absorber with retaining spring: The door may not close completely if the closing speed is too low, if it is too high, the door may bounce back slightly.For sets without or with soft and self closing mechanism on one side: If required, soft and self closing mechanism or shock absorber can be retrofitted.



    End cap for ceiling installation with fascia on both sides not available. One pair of end caps can be glue fixed vertically in the centre of the running track (optional).

  • Data Sheet

  • Product Resources

  • Required Products & Optional Accessories

    Note: Add the current product in cart before ordering required products below ...

    Required Products:

    Single Running Track, Pre-drilled, W x H: 31 x 33 mm (choose one):
    • For Slido D-Line11, Mill Finish, Length: 6’ 6 3/4” (2 m)
      For Slido D-Line11, Clear Anodized Finish, Length: 6' 6 3/4" (2 m)
      For Slido D-Line11, Mill Finsh, Length: 9’ 10 1/8” (3 m )
      For Slido D-Line11, Clear Anodized Finish, Length: 9' 10 1/8" (3 m)
      For Slido D-Line11, Mill Finish, Length: (19’ 8 1/4”) 6 m
      For Slido D-Line11, Clear Anodized Finish, Length: 19' 8 1/4" (6 m)      		940.43.921
      940.43.922
      940.43.931
      940.43.932
      940.43.961
      940.43.962      		Click to order
      Click to order
      Click to order
      Click to order
      Click to order
      Click to order


    Single running track, Pre-drilled, W x H: 47.5 x 47 mm (choose one):
    • For Slido D-Line11, Aluminum, silver colored anodized, length: 3,000 mm940.43.930Click to order


    Single Upper Track, Wall mounted (choose one):
    • For Slido D-Line11, Aluminum, clear anodized, length 2000 mm
      For Slido D-Line11, Aluminum, clear anodized, length 3000 mm
      For Slido D-Line11, Aluminum, clear anodized, length 6000 mm      		941.25.602
      941.25.603
      941.25.606      		Click to order
      Click to order
      Click to order


    Double running track, Pre-drilled, W x H: 70 x 33 mm (choose one):
    • For Slido D-Line11, Aluminum, silver colored anodized, length: 2,000 mm
      For Slido D-Line11, Aluminum, silver colored anodized, length: 3,000 mm
      For Slido D-Line11, Aluminum, silver colored anodized, length: 6,000 mm      		941.02.920
      941.02.930
      941.02.960      		Click to order
      Click to order
      Click to order


    Double Running Track, Pre-Drilled, W x H: 81 x 33 mm (choose one):
    • For Slido D-Line11, clear anodized, length: 2,000 mm
      For Slido D-Line11, unfinished; length: 2,000 mm
      For Slido D-Line11, clear anodized, length: 3,000 mm
      For Slido D-Line11, unfinished; length: 3,000 mm
      For Slido D-Line11, clear anodized, length: 6,000 mm      		941.02.820
      941.02.821
      941.02.830
      941.02.831
      941.02.860      		Click to order
      Click to order
      Click to order
      Click to order
      Click to order


    Optional Accessories:

    • Soft and Self Closing Mechanism, Slido Classic
    • Shock absorber, Slido Classic
    • Mounting rail, Pre-drilled, width 19 mm
    • Mounting rail, pre-drilled, width 8 mm
    • Mounting Rail, High, Pre-Drilled, Width 19 mm
    • Mounting Rail, High, Pre-Drilled, Width 8 mm
    • Safety Pin and Safety Screw Set, For Running Track and Mounting Rail
    • Mounting bracket, with screw and nut
    • Clip-on panel, for running track
    • Clip-on panel, for running track
    • End cap set, for running track 31 x 33 mm (W x H)
    • End cap set, Height 68 mm, for running track with panel 12.5 x 68 mm (W x H)
    • End Cap Set, for Häfele Slido D-Line11, height 68 mm
    • Floor Guide, Plastic, Gray
    • Floor Guide, Slido Classic 40-P-120-P
    • Sliding Door Hardware, Slido D-Line11 Synchro, additional set for 50-P to 80P
    • Track Stopper, Slido D-Line11 additional set for 50P-120P, 50C-120C, 50I-120I
    • Fitting set, Slido D-Line11 Stacking Additional Set for 50P–120P, 50C–120C and 50I–120I

  • Brand PDF Catalogs

Cannot find your product? click: Help!. Our product experts will assist you.

Quick Metric Conversions: 25mm = 1 inch (approx), 2.5cm = 1 inch (approx), 96mm = 3.75 inches
