Hafele 941.04.003 Hawa Junior 100/Z Fitting set, with 1 soft stop and 1 soft close mechanism (1 kit), 94104003, 941-04-003Zoom

Hafele 941.04.003 Hawa Junior 100/Z Fitting set, with 1 soft stop and 1 soft close mechanism

$552.58$690.72You Save: $138.14 (20%)
Item# Hafele-941-04-003
Availability: in stock (83 or less)

Product Information

  • Description

    Manufacturer: Hafele
    Item: 941.04.003

    Product Title: Sliding door fitting, Hawa Junior 100 Z /100 Z Pocket, set, for 1-leaf and 2-leaf wooden sliding doors, height adjustable, two-way suspension, for door weight up to 100 kg, with SoftMove 100 soft and self closing mechanism on one side, with SoftStop on one side

    Category: Sliding door fitting, Hawa Junior 100 Z /100 Z Pocket, set, for 1-leaf and 2-leaf wooden sliding doors, height adjustable, two-way suspension, for door weight up to 100 kg

    Item Details …

    -     low opening force – easy and convenient operation

    - Barrier-free due to low operating force

    - new, Hawa SoftMove 100 soft and self closing mechanism

    - Push-to-Open function due to spring buffer, for ejecting the fully inserted door from the wall pocket

    - Number of doors per system max. : 1 to 2

    - Number of doors : 1.00

    - For door material : wood

    - For door weight : ?100 kg

    - Controller installation options : Ceiling installation, Wall mounting, Wall pocket solution

    - For door thickness : 35?–?80 mm

    - Adjustment facility : Height adjustment: ±4 mm, Door side adjustable,Track buffer with adjustable retaining spring

    - Area of application : for 1-leaf and 2-leaf sliding doors

    - Note on door width : The max. door width for the pocket door solution is 1,500 mm.

    - For door height : ?4,000 mm

    - Running position : Top

    - Installation : Suspension with screwed on two-way suspension

    - Installation reference : The door can be installed and removed from the front or the side.Pocket door solution: subsequent disassembly of the running track is possible without opening the wall, running gear and soft and self closing mechanism can be removed, Stopper position in the wall pocket, readjustable.

    - Door processing : for screw fixing

    - Supplied with:

    - 1 running gear

    - 1 running gear with soft and self closing mechanism, incl. release device and stopper

    - 2 two-way suspensions

    - 1 clear threshold floor guide 60 mm

    - 1 SoftStop with retaining spring

    - 1 wall buffer

    - Accessories


    Additional Information …

    The greater distance between the door leaf and the wall results in greater demands on the load bearing capacity of the wall (lever effect). Sufficient load bearing capacity must be ensured.No end cap is available for ceiling installation with fascia on both sides.A pair of end caps can be attached end to end and glued vertically in the centre of the running track (optional).

  • Data Sheet

  • Product Resources

  • Required Products & Optional Accessories

    Note: Add the current product in cart before ordering required products below ...

    Required Products:

    Upper Track, Pre-drilled (choose one):
    • for Hawa Symmetric, Telescopic, Junior, 1.4 m (4’ 7 1/8”)
      for Hawa Symmetric, Telescopic, Junior, 1.6 m (5’ 3”)
      for Hawa Symmetric, Telescopic, Junior, 1.8 m (5’ 10 7/8”)
      for Hawa Symmetric, Telescopic, Junior, 2 m (6’ 6 3/4”)
      for Hawa Symmetric, Telescopic, Junior, 2.2 m (7’ 2 5/8”)
      for Hawa Symmetric, Telescopic, Junior, 2.5 m (8’ 2 7/16”)
      for Hawa Symmetric, Telescopic, Junior, 3 m (9’ 10 1/8”)
      for Hawa Symmetric, Telescopic, Junior, 4 m (13’ 1 1/2”)
      for Hawa Symmetric, Telescopic, Junior, 6 m (19’ 8 1/4”)      		940.80.140
      940.80.160
      940.80.180
      940.80.200
      940.80.220
      940.80.250
      940.80.300
      940.80.400
      940.80.600      		Click to order
      Click to order
      Click to order
      Click to order
      Click to order
      Click to order
      Click to order
      Click to order
      Click to order


    Running track, for wall mounting, pre-drilled, for aluminium or wooden panel (choose one):
    • for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 2,000 mm
      for Hawa Junior 80/100, length: 2,500 mm
      for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 3,000 mm
      for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 4,000 mm
      for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 6,000 mm      		941.04.600
      941.04.601
      941.04.602
      941.04.603
      941.04.604      		Click to order
      Click to order
      Click to order
      Click to order
      Click to order


    Running track, for ceiling installation, pre-drilled, for aluminium or wooden panel (choose one):
    • for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 2,000 mm
      for Hawa Junior 80/100, length: 2,500 mm
      for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 3,000 mm
      for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 4,000 mm
      for Hawa Junior 80/100, aluminium, silver coloured anodized, length: 6,000 mm      		941.04.605
      941.04.606
      941.04.607
      941.04.608
      941.04.609      		Click to order
      Click to order
      Click to order
      Click to order
      Click to order


    Guide Rail, 20 x 12 (13/16" x 1/2"), Glue-in (choose one):
    • for Hawa Junior, Symmetric, Telescopic, Ordena, (4' 3 1/8") 1.3 m940.41.130Click to order


    Optional Accessories:

    • Spacer Profile, Pre-drilled, for wall mounting the combination track, 11 x 36 mm (W x H)
    • Clip-on panel, for wooden doors, height 77 mm
    • Clip, for Wood and Aluminum Fascia, 97 x 29 x 9.5 mm
    • Cover Cap, For running track
    • End cap set, for clip-on panel height 77 mm
    • Clip-on panel, For fixing profile, for transom facing
    • Buffer, with retaining spring
    • SoftStop, with retaining spring
    • Spring buffer, for Hawa Junior 80
    • Soft and self closing mechanism, SoftMove 100, for Hawa Junior 100
    • Bar Bolt Lock, Hawa Doorfix
    • Sealing Profile, Drilled

  • Brand PDF Catalogs
