Hafele 941.25.014 Slido D-Line11 120L Fitting Set, with 2 track stoppers

$112.91$141.14You Save: $28.23 (20%)
Item# Hafele-941-25-014
Availability: limited availability (4 or less)

Product Information

  • Description

    Manufacturer: Hafele
    Item: 941.25.014

    Product Title: Sliding door fitting, Slido D-Line11 120L, set without running track, For 1-leaf glass sliding doors, for door weight 120 kg, without soft and self closing mechanism, Running gear with axle bearing, Track buffer with retaining spring, door width: ?500 mm

    Category: Sliding door fitting, Häfele Slido D-Line11 50L / 80L / 120L, set without running track, For 1-leaf glass sliding doors, for door weight 50–120 kg

    Item Details …

    -     Soft and self closing mechanism:

    - low opening force – easy and convenient operation

    - tested with increased closing speed up to 0.5 m/s

    - Can be retrofitted or replaced at any time

    - Accessibility: Opening force with door weight 50 kg: 18 N / 80 kg: 21 N

    - Shock absorber:

    - Closing speed with shock absorber tested up to 0.4 m/s

    - Number of doors per system max. : 1 to 2

    - Number of doors : 1.00

    - For door material : glass

    - Controller installation options : Ceiling installation, Wall mounting

    - For glass thickness with tempered safety glass : 8 mm, 10 mm, 12.7 mm

    - For glass thickness with laminated glass : 8–8,7 mm, 10–10,7 mm

    - Adjustment facility : Height adjustment: ±4 mm

    - Area of application : for 1-leaf and 2-leaf sliding doors

    - Note on door thickness : For tempered safety glass: 3/8" and 1/2"For laminated glass: 11/32" and 7/16"

    - Running position : Top

    - Installation reference : No end cap is available for ceiling installation with fascia on both sides. A pair of end caps can be attached end to end and glued vertically in the centre of the running track (optional).

    - Order reference

    - Please order glass clamp shoe, tracks, panels and accessories separately.

    - Order 2 sets for 2-leaf sliding doors.

    - Supplied with:

    - 2 running gears

    - 1 clear threshold floor guide

    - 2 track buffer with retaining spring


    Additional Information …

    Please note when using shock absorber with retaining spring: The door may not close completely if the closing speed is too low, if it is too high, the door may bounce back slightly.For sets without or with soft and self closing mechanism on one side: If required, soft and self closing mechanism or shock absorber can be retrofitted.

  • Data Sheet

  • Product Resources

  • Required Products & Optional Accessories

    Note: Add the current product in cart before ordering required products below ...

    Required Products:

    Mounting Rail, High, Pre-Drilled, Width 8 mm (choose one):


    Mounting Rail, High, Pre-Drilled, Width 19 mm (choose one):


    Single Running Track, Pre-drilled, W x H: 31 x 33 mm (choose one):
    • For Slido D-Line11, Mill Finish, Length: 6’ 6 3/4” (2 m)
      For Slido D-Line11, Clear Anodized Finish, Length: 6' 6 3/4" (2 m)
      For Slido D-Line11, Mill Finsh, Length: 9’ 10 1/8” (3 m )
      For Slido D-Line11, Clear Anodized Finish, Length: 9' 10 1/8" (3 m)
      For Slido D-Line11, Mill Finish, Length: (19’ 8 1/4”) 6 m
      For Slido D-Line11, Clear Anodized Finish, Length: 19' 8 1/4" (6 m)      		940.43.921
      940.43.922
      940.43.931
      940.43.932
      940.43.961
      940.43.962      		Click to order
      Click to order
      Click to order
      Click to order
      Click to order
      Click to order


    Single running track, Pre-drilled, W x H: 47.5 x 47 mm (choose one):
    • For Slido D-Line11, Aluminum, silver colored anodized, length: 3,000 mm940.43.930Click to order


    Double running track, Pre-drilled, W x H: 70 x 33 mm (choose one):
    • For Slido D-Line11, Aluminum, silver colored anodized, length: 2,000 mm
      For Slido D-Line11, Aluminum, silver colored anodized, length: 3,000 mm
      For Slido D-Line11, Aluminum, silver colored anodized, length: 6,000 mm      		941.02.920
      941.02.930
      941.02.960      		Click to order
      Click to order
      Click to order


    Optional Accessories:

    • Soft and Self Closing Mechanism, Slido Classic
    • Shock absorber, Slido Classic
    • Safety Pin and Safety Screw Set, For Running Track and Mounting Rail
    • Profile, Self-Adhesive, for 8 - 10 mm (5/16 - 13/32") Thick Glass
    • Centering Door Stop, For glass thickness 8, 10, 12 mm
    • Track Stopper, Slido D-Line11 additional set for 50P-120P, 50C-120C, 50I-120I
    • Clip-On Fascia, For Running Track
    • Wrench, for Height Adjustment
    • Gasket, For Glass Thickness (3/8") 10mm
    • Fixed Glass Fixing Profile, For Wall or Floor
    • Fixed Glass Fixing Profile, For Upper Running Track
    • End Cap Set, For Clip-On Fascia Cover
    • Floor Guide, Nickel Plated, Matt, for Glass Thickness: 8.10, 12.7 mm
    • End cap set, For running track and panel
    • Clip-on panel, for running track
    • Clip-on panel, For running track, for integration in suspended ceilings
    • Mounting bracket, with screw and nut
    • Glass Door Lock, Toplock for European Profile Cylinder
    • Upper Track Cleaning Tool, For Hawa Porta, Divido
    • Sliding Door Hardware, Slido D-Line11, additional set for 50-L-120-L
