Hafele 942.41.000 Sliding Door Hardware, Hawa Super 500/B, set Top Hung System

Product Information

• Description

  Manufacturer: Hafele
  Item: 942.41.000

  Product Title: Sliding Door Hardware, Hawa Super 500/B, set, Top Hung System, without double running track

  Category: Sliding Door Hardware, Hawa Super 500/B, set, Top Hung System, without double running track

  Item Details …

  - Robust but easy running

  - Vertically adjustable

  - Extremely resistant to wear and tear

  - Suspension with carrier bracket

  - Number of doors per system max. : 1 to 2

  - Number of doors : 1.00

  - For door material : wood

  - Model : 500 B

  - For door weight : ?500 kg

  - Controller installation options : Ceiling installation

  - Adjustment facility : Height adjustment: ±2 mm, Height ±2 mm

  - For door thickness min. : 1 3/8"

  - Load bearing capacity : 1100 lbs.

  - Area of application : For single and bypassing sliding wood doors

  - Suitable for : Minimum installation height

  - Running position : Top

  - Installation : Suspension with recessed suspension bracket

  - Door processing : With recess

  - Order reference

  - Order 2 sets for 2-leaf sliding doors.

  - Supplied with:

  - 2 running gears

  - 2 suspension brackets with support carriage and M12 hanger bolt

  - 2 spring buffers for recess mounting in door leaf

  - 1 floor guide

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  Installation instructions

  TCH_Architectural_Hardware_2022|Page 1.143



• Specifications

  For detailed PDF specifications, click:
  Hafele Sliding Door Catalog Page: selection_1.92-1.93.pdf

  Hafele 942.41.000 HAWA Super 500/B Fitting Set


  • Hardware > Building Materials > Door Hardware
  • Hardware,Hafele,500-3000
  • Brand: Hafele
  • Part#: 942.41.000
  • Condition: new

• Required Products & Optional Accessories

  Note: Add the current product in cart before ordering required products below ...

  Required Products:

  Dual Upper Track, with Mounting Flanges, Ceiling Mounted (choose one):


  • for Hawa Super, stainless steel, shot-blasted, length 6,000 mm

    942.43.611

    Click to order



  Optional Accessories:



  • Buffer, Hawa Super 500 B
  • Cover Plate, for Suspension Brackets
  • Bar Bolt Lock, Hawa Doorfix
  • Sealing Profile, Drilled
  • Floor Guide, Hawa-Confort 120, 1-piece
