Hafele 942.72.004 Slido Pocket Door Framing Kit, for doors up to 96" tall and 40" wide

Product Information

• Description

  Manufacturer: Hafele
  Item: 942.72.004

  Product Title: Pocket Door Frame Set, Slido, For 96" tall door

  Category: Pocket Door Frame Set, Slido,

  Item Details �

  - After installationthe system components are serviceable because the track can be removed without opening up the drywall

  - Specially bent steel reinforced split studs prevent bowing of the pocket walls

  - Simple and straight forward installation

  - For door thickness max. : 1 3/4"

  - For door width (inches) : Max: 40"

  - Load bearing capacity : 88 - 264 lbs.

  - Area of application : Provides an effective way to save space in tight rooms and frees up typically unused wall and floor areas

  - Order reference

  - For bi-parting applications order 2 sets. The sliding fitting sets need to be ordered separately. Refer to the respective catalog pages for the Slido Classic 40-P, 60-P, 80-P, and 120-P.

  - Supplied with:

  - Header assembly

  - Front & back vertical stud with aspen wood strip

  - Shoe plate

  - Concealed end bracket

  - Open end bracket

  - Filler strip

  - Upper track

  - Screw pack

• Data Sheet

  Detailed Data Sheet

• Product Resources

  Slido Pocket Door Framing Kit Mounting Instructions

  TCH_Architectural_Hardware_2022|Page�1.225
