Hafele 940.59.812 Guide track, for soft floors Slido Design 80-M, Silver colored anodized, length: 2,200 mm

Product Information

• Description

  Manufacturer: Hafele
  Item: 940.59.812

  Product Title: Bottom track, for soft floors, Slido Design 80-M, Black anodized, length: 2,200 mm

  Category: Bottom track, for soft floors, Slido Design 80-M

  Item Details …

  - Product type : Bottom track

  - For door width : 800?–?1,800 mm

  - Width : 30.00 mm

  - Width (inch) : 1 3/16"

  - Height : 5.00 mm

  - Height (inch) : 5/32"

  - Load bearing capacity : 176 lbs.

  - Area of application : For soft floors

  - Material : Aluminum

  - Position : bottom

  - For door weight : ?80 kg

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  TCH_Architectural_Hardware_2022|Page 1.13

  TCH_Architectural_Hardware_2022|Page 1.239



• Specifications

  For detailed PDF specifications, click:
  Hafele Sliding Door Catalog Page: selection_1.26-1.27.pdf

  Hafele 940.59.812 Slido Design 80-M Support Track, for soft floors, al


  • Hardware > Building Materials > Door Hardware
  • Hardware,Hafele,10-50
  • Brand: Hafele
  • Part#: 940.59.812
  • Condition: new

• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Optional Accessories:



  • Sliding door fitting, Slido D-Line43 80N, frame door for glass and wooden panel
