Hafele 941.00.007 Sliding Door Hardware, EKU Porta 100 GU/G/GF/GFO Set EKU Porta 100 G/GF/GFO/GU/GM

Product Information

• Description

  Manufacturer: Hafele
  Item: 941.00.007

  Product Title: Sliding Door Hardware, HAWA Porta 100 GU/G/GF/GFO, set, For 1 slidnig door, without running track

  Category: Sliding Door Hardware, HAWA Porta 100 GU/G/GF/GFO, set, For 1 slidnig door, without running track

  Item Details …

  - Smooth quiet operation

  - Maintenance-free

  - Rattle-free bottom guide

  - Simple installation

  - No glass cut-outs required

  - Vertical adjustment without removing the glass door

  - Number of doors per system max. : 1 to 2

  - Number of doors : 1.00

  - For door material : glass

  - Model : Porta 100 GU

  - Version : Aluminium clip panel or clip part for wooden panel (optional)

  - Soft closing mechanism : with soft closing mechanism (optional)

  - For door weight : ?100 kg

  - For door width : ?1,200 mm

  - Controller installation options : Ceiling installation, Wall mounting, Fixed glass panels

  - For glass thickness with tempered safety glass : 8 mm, 10 mm, 12 mm, 12.7 mm

  - Adjustment facility : Height adjustment: ±4 mm, Height: +10, –5 mm, door side adjustable

  - Door weight max. : 220 lbs.

  - For min. glass thickness (inches) : 1/4" - 1/2"

  - Area of application : For 1 and 2 sliding glass doors

  - For door height : ?2,700 mm

  - For glass type : Tempered safety glass

  - Running position : Top

  - Door processing : Without glass preparation

  - Order reference

  - Order 2 sets for 2-leaf sliding doors.

  - Supplied with:

  - 2 running gears

  - 2 suspension screws M8 x 32

  - 2 nuts

  - 2 clamping shoes

  - 2 track stoppers (1 with retaining spring, 1 without retaining spring)

  - 1 wall buffer

  - 1 clear threshold floor guide

• Data Sheet

  Detailed Data Sheet

• Product Resources

  CAD data

  Installation instructions

  TCH_Architectural_Hardware_2022|Page 1.257

  TCH_Architectural_Hardware_2022|Page 1.259

  TCH_Architectural_Hardware_2022|Page 1.261



• Specifications

  For detailed PDF specifications, click:
  Hafele Sliding Door Catalog Page: selection_1.210-1.211.pdf

  Hafele 941.00.007 EKU Porta 100 Fitting Set


  • Hardware > Hardware Accessories
  • Hardware,Hafele,50-500
  • Brand: Hafele
  • Part#: 941.00.007
  • Condition: new
