Hafele 941.20.011 Sliding door fitting, Hawa Junior 120/G For 1 and 2 sliding glass doors

Product Information

• Description

  Manufacturer: Hafele
  Item: 941.20.011

  Product Title: Sliding door fitting, Hawa Junior 120/G, For 1 and 2 sliding glass doors

  Category: Sliding door fitting, Hawa Junior 120/G, For 1 and 2 sliding glass doors

  Item Details …

  - Smooth and quiet operation

  - Maintenance-free

  - Simple installation

  - Vertical adjustment without removing the glass door

  - Elegant design of continuous top and bottom glass suspension profile

  - Number of doors per system max. : 2

  - Number of doors : 1.00

  - For door material : glass

  - For door weight : ?120 kg

  - Door weight max. : 264 lbs

  - For min. glass thickness (inches) : 3/8, 15/32, 1/2"

  - Area of application : For 1 and 2 sliding glass doors

  - Supplied with:

  - 2 x running gear

  - 2 x suspension bolt

  - 2 x track stopper

  - 1 x cover cap

  - 1 x wall buffer

  - 1 x locking wrench

• Data Sheet

  Detailed Data Sheet

• Product Resources

  TCH_Architectural_Hardware_2022|Page 1.317



• Brand PDF Catalogs

  Click on a Category to open a PDF catalog:

  Sliding and Folding Catalog

  Fineline Brochure

  Free Flap Fittings Brochure

  The Complete Architectural Hardware Catalog

  Dialock In Hotels Catalog

  Dialock System Catalog

  IXConnect Invisible Heroes

  One Room One Face Catalog

  Architectural Hardware: American Standard Catalog

  Closet Catalog

  Decorative Wood Catalog

  Cornerstone Catalog

  Decorative Hardware Catalog

  Kitchen Solutions Catalog

  Loox5 Lighting Catalog

  Furniture Cabinetry Hardware Catalog

  Designing Accessibility HEWI Catalog

  The Complete Cabinet



• Required Products & Optional Accessories

  Note: Add the current product in cart before ordering required products below ...

  Required Products:

  Lower Guide Channel, Pre-drilled (choose one):


  • For Hawa Junior, length: 6 m (19' 8 1/4")

    946.03.600

    Click to order



  Lower Guide Channel, Pre-drilled (choose one):


  • for Hawa Telescopic, Junior, folding wall, Length: 2.5 m (8' 2 7/16") for Hawa Telescopic, Junior, folding wall, Length: 6.0 m (19' 8 1/4")

    941.00.925 941.00.960

    Click to order Click to order



  Running track, pre-drilled, door weight up to 120 kg (choose one):


  • For Hawa Junior, (8' 2 7/16") 2.5 m For Hawa Junior, (9’ 10 1/8”) 3 m For Hawa Junior, (13’ 1 1/2”) 4 m For Hawa Junior, (19’ 8 1/4”) 6 m

    941.20.250 941.20.300 941.20.400 941.20.600

    Click to order Click to order Click to order Click to order



  Optional Accessories:



  • Single Lower Guide, Zero clearance, for glass thickness 8, 10, 12 (12.7) mm
  • Cover Cap, for Glass Suspension Profile (3/16 - 13/32") 12–16 mm
  • Glass Holder Insert, with M6 x 30 (1 3/16") Screw
  • Support and Glass Suspension Profile, For glass thickness: (15/32 - 5/8") 12–16 mm
  • Support and Glass Suspension Profile, For glass thickness: (3/16 - 13/32") 8–10 mm
  • Cover Cap, for Glass Suspension Profile (15/32 - 5/8") 12–16 mm
  • Lower Guide, with Slider and Suspension Block
  • Door Stop, Floor Mounted, Aluminum
  • Anodized Aluminum
